| MODEL | Configuration | Input MBtuH | Output MBtuH | AFUE | CFM | Dimensions HxWxD | Weight Lbs. |
|---|---|---|---|---|---|---|---|
| S9X2B040U2PSAA | Upflow /Hor. | 40.0 | 38.8 | 95.0 | 1161 | 34x17.5x28.75 | 114 |
| S9X2B040U3PSAA | Upflow /Hor. | 40.0 | 38.8 | 95.0 | 1338 | 34x17.5x28.75 | 114 |
| S9X2B060U3PSAA | Upflow /Hor. | 60.0 | 58.2 | 95.0 | 1496 | 34x17.5x28.75 | 119 |
| S9X2B060U4PSAA | Upflow /Hor. | 60.0 | 58.2 | 95.0 | 1723 | 34x17.5x28.75 | 122 |
| S9X2B080U3PSAA | Upflow /Hor. | 80.0 | 77.6 | 95.0 | 1603 | 34x17.5x28.75 | 124 |
| S9X2B080U4PSAA | Upflow /Hor. | 80.0 | 77.6 | 95.0 | 1677 | 34x17.5x28.75 | 127 |
| S9X2C080U4PSAA | Upflow /Hor. | 80.0 | 77.6 | 95.0 | 1928 | 34x21x28.75 | 139 |
| S9X2C080U5PSAA | Upflow /Hor. | 80.0 | 77.6 | 95.0 | 1928 | 34x21x28.75 | 139 |
| S9X2C100U4PSAA | Upflow /Hor. | 100.0 | 97.0 | 95.0 | 2338 | 34x21x28.75 | 144 |
| S9X2C100U5PSAA | Upflow /Hor. | 100.0 | 97.0 | 95.0 | 2305 | 34x21x28.75 | 144 |
| S9X2D120U5PSAA | Upflow /Hor. | 120.0 | 116.4 | 95.0 | 2369 | 34x24.5x28.75 | 156 |
| S9X2B040D2PSAA | Downflow | 40.0 | 38.8 | 95.0 | 1161 | 34x17.5x28.75 | 114 |
| S9X2B060D3PSAA | Downflow | 60.0 | 58.2 | 95.0 | 1496 | 34x17.5x28.75 | 119 |
| S9X2B080D4PSAA | Downflow | 60.0 | 58.2 | 95.0 | 1603 | 34x17.5x28.75 | 122 |
| S9X2C100D5PSAA | Downflow | 100.0 | 97.0 | 95.0 | 2338 | 34x21x28.75 | 145 |
| S9X2D120D5PSAA | Downflow | 120.0 | 116.4 | 95.0 | 2369 | 34x24.5x28.75 | 145 |
